REVERSE ENGINEERING & AS-BUILT DRAWINGS
Helping to create a record for items that the drawings and schematics do not exist for.
Reverse Engineering
If you have the physical item that you need drawings and/or analysis for, we can arrange a site visit to take all necessary details to create a new model.
Or, if you have an old set of drawings, perhaps not fully legible, we can use them to create a new set and incorporate any changes required and carry out all functional and strength checks.
As-Built Drawings
Even after designs have been reviewed by several people, the design can still change during manufacture. When this happens, it’s important to keep a record of the changes by means of an as-built drawing. We can help with this by being in contact with the workshop or point of contact for the manufacture and and can capture the changes as they arise.
